Baseball Swing Plane Experiment: Staying Low Like Stephen Vogt

, ,

Getting Under The Ball Like Stephen Vogt – A Baseball Swing Plane Experiment



Baseball Swing Plane: Stephen Vogt

August 2014  Stephen Vogt (21) hits a solo home run. Mandatory Credit: Kyle Terada-USA TODAY Sports

Stephen Vogt side note: CLICK HERE to watch video of him doing referee impersonations, he’s apparently known for, on Intentional Talk.  That’s Johnny Gomes in the background 😀

Question: Can the Back Leg Angle Affect Ball Flight During the Final Turn?

Using the Zepp (Labs) Baseball app, I wanted to use the Scientific Method to analyze the effect the back leg angle has on ground balls, line drives, and fly balls.

Background Research

Two posts I’ve written that talk about the back leg angle:

In the above posts, pay particular attention to what Homer Kelly says about Knee Action.

As of the beginning of May 2015, Stephen Vogt of the Oakland Athletics, is ranked 2nd overall in OPS at 1.179 (according to MLB.com’s sortable stats).  Can he hold this up all year?  Maybe, maybe not.  But the metrics I’m about to reveal have a solid base in his back leg angle mechanics.

He has a very distinct back leg angle during the Final Turn and follow through (see image above).  Here’s how his metrics stacks up over four seasons, against the league average (according to FanGraphs.com):

  • Ground ball% – Stephen Vogt (32.6%), League Average (44%)
  • Line Drive% – Stephen Vogt (20.7%), League Average (20%)
  • Fly Ball% – Stephen Vogt (46.6%), League Average (36%)
  • Home-run/Fly-ball Ratio – Stephen Vogt (10%), League Average (9.5%)

So he’s well below the league average in ground-balls, slightly higher in line drives, and has  a 0.5% higher home-run to fly-ball percentage.  The latter meaning what percentage of his fly-balls go over the fence.  Lastly, as you can clearly see, Stephen Vogt has an above average fly-ball percentage.  Remember, fly-balls aren’t always bad.  Most times, they’re more productive than ground-balls in sacrificing runners over or bringing them in to score.



Hypothesis

Based on the above research and with my own experience, I think that having the back leg angle bent in an “L” (or 90-degree angle) during the Final Turn and follow through will produce more elevated line drives and fly balls.  Whereas a straighter back leg angle (closer to 180-degrees) will produce more low level line drives and ground balls.



Baseball Swing Plane Experiment: “Staying Low”

Babe Ruth Hand-Tension Experiment Setup

Here was how I setup the experiment “work station”

Equipment Used:

Setup:

  • Yellow dimple ball feedback markers = my bat length, plus two baseballs
  • Distance from plate = end of the bat touching inside corner of plate, and knob of bat touching my mid-thigh.
  • Tee was set slightly behind the front feedback marker, and tee height was about mid-thigh.
  • First 100 baseballs were hit with a 90-degree back leg angle during the Final Turn and follow through.
  • Second 100 baseballs were hit a straighter back leg angle (about 170-degrees) during the Final Turn and follow through.

Data Collected (Zepp Baseball App Screenshots):

Baseball Swing Plane Zepp Experiment: "Staying Low"

Fig.1: Here are the averages of both sessions. Pay particular attention to the “Bat Vertical Angle at Impact” and “Attack Angle” preferences…

According to the Zepp app user guide, let’s define the following terms:

  • Bat Vertical Angle at Impact – This is the Vertical angle (Up or Down) measured in degrees, of your bat barrel in relation to the knob of the bat, when it makes impact with the ball.
  • Attack Angle – Attack Angle is the direction the bat barrel is moving (Up or Down) at impact. A positive number would mean your barrel is going UP at impact, zero is LEVEL and a negative number is the barrel going DOWN at impact.

Check out the ground-ball, line drive, and fly-ball comparison:

Baseball Swing Plane Experiment: Ball Flight

Fig.2: Check out the difference in ball flight between the two sessions. Pay particular attention to the ground-ball percentages.

Data Analysis & Conclusion

I wasn’t paying too much attention to bat and hand speed on this experiment.  I only focused on the metrics indicating a change in ball flight.

  • Attack angle had a 3-degree difference according to Fig.1.
  • Bat Vertical Angle at Impact also had a 3-degree difference according to Fig.1.
  •  27% difference in ground-ball% according to Fig.2.
  • 24% difference in fly-ball% according to Fig.2.

Notes

Baseball Swing Plane Experiment: Cage Labels

This were the rules I used for ball flight in the cage during the Experiment.

  • Here’s a picture (image to the right) of the cage I hit in and the labels for each batted ball outcomes.
  • I’m not sure why the Bat Vertical Angle at Impact was larger for the “Straight Back Knee”.  Maybe it had to do with my back knee starting bent towards impact, but then the barrel compensated by “pulling up” to accommodate the straightening back knee.  This disturbance in the pitch plane is NO bueno.
  • I found myself reverting back to old habits (Bent Back Knee) during the Straight Back Knee session.  There were at least a dozen balls I hit that had more bend than I wanted during that session.
  • During the “Bent Back Knee” session, about 65% of my fly-balls were “shots”, and didn’t hit the back of the cage to be considered a line drive.
  • I find with small sluggers like Stephen Vogt bend their back knee between 90-105 degrees during the Final Turn.  With fastpitch softball, the angle of the back knee isn’t quite so drastic because of the reduced plane of the pitch.  If I can get my softball players to be 105-120 degrees with the back knee angle, then I’m happy.



In Conclusion

So the back knee angle during the Final Turn does have a significant impact on ball flight.  More bend equals, more airtime for the ball.  I’ve seen Little Leaguers to Pro hitters straightening out their back legs.  And they often wonder why they aren’t driving the ball.

In terms of driving the ball like Stephen Vogt, think of the back leg angle as angling your body like a “ramp”.  Also, take a look at smaller sluggers (6’0″, 225-lbs on down) like: Adrian Beltre, Stephen Vogt, Jose Bautista, Josh Donaldson, and Andrew McCutchen as great examples of back knee bend.

Joey Myers
Follow Me
11 replies
  1. Bob
    Bob says:

    That Zepp thing looks like a cool device. It’s amazing the way science has changed sports. It’s one reason the players of today are that much better than those of yester-years. There are other reasons such as training methods, nutrition, etc., but I think we’ve reached the point where we can’t really compare the athletes of today with those that played before. Today in baseball you have pitchers that will be pulled after two bad pitches, when back in the day you would see a guy pitch half a game a day and a half after he pitched a full game! He may only be throwing 78 miles an hour down the middle of the plate etc by then. They clock every pitch, and if a guys fastball gets to be two miles an hour under what they expect of him, you’ll see a visit from the mound. Hitting is the same way. These guys now are so sophisticated in their approach, that they’d chew up 99% of the guys who are in the Hall. That’s not to slight any of the past greats, but if you dropped Mike Trout or Chris Davis into a game in the 50’s and they saw what they were throwing, it would be like a home run derby.

    • Joey Myers
      Joey Myers says:

      I get you there Bob. Yes, I think we’re moving from being so slow motion video analysis conscious to more data driven. The former being the dinosaur. We now have access to SABR-metrics and “Zepp” type of devices to tinker and test mechanics and really see what the game is telling us we need to work on.

      I do think hitting eras are relative though…yes pitching, a heavy reliance on relief pitching, and higher top out speeds have made hitting more challenging. But I think if you threw Ruth, Williams, Mays, etc. into the mix today, there would be an adjustment, but I think they’d hold their own over time. Would their numbers be as high? Maybe, maybe not.

      I think pitching has gotten better, but hitting has gotten worse. Both mechanics and the way we train (using variance, as an example). The reason more frequent relief pitching has had such an effect on dampening offenses is because players and coaches are so obsessed with “massed practice”. I need to work on hitting the ball the other way, so I’ll take 200 swings off a tee with it simulating an outside pitch. No pitcher EVER has been able to put the ball on the same exact outside corner spot 200 times in a row. We’re ignorant if we train hitters this way.

      There needs to be more variance infused into a hitter’s training, to deal with the variance that hitting an unknown moving pitch gives us. You can train almost any scenario and situation for a hitter. We as coaches, just have to be more creative with science’s research and study that’s out there.

    • Joey Myers
      Joey Myers says:

      Enele, I hear you there. The problem with LIVE pitching is it creates too much of a variable. A tee (Backspin tee included) or SwingAway helps to isolate the experiment variables. The following experiments I did will be with a SwingAway. It cuts my experiment time in half!

  2. Bob hill
    Bob hill says:

    You can have a great swing and still be the worst hitter. Your swing might look bad and be the best hitter. I think in order to be a better hitter you need to stay away from soft toss and all the other gimmicks. You need to train your eyes watch the ball timing is everything. Live arm action is best training.

    • Joey Myers
      Joey Myers says:

      Of course. Anything that resembles game pitching is always the best option. HOWEVER, to get a young hitter to break down, then build up new mechanics, a coach cannot expect to get anywhere without a tee or shortened soft or LIVE toss.

  3. Bob
    Bob says:

    There’s always that ‘chicken and egg’ thing with hitting. What comes first … having a good swing or being able to make contact? For my money … develop the swing first and then let the brain and eyes catch up as the player gains confidence and learns to read pitchers. It’s sometimes too much to ask for young players to have the mental approach and concentration of an adult, but they can sure enough swing like one in terms of mechanics. When you talk about timing and consistency, you are talking about getting the bat head from point A to point B in X amount of time – every time! To do this and have an innate sense of what your speed is, and be very familiar with how long that takes. If your swing is all over the place I.E. you step different, have the bat in a different place every time at launch, slow down or speed up your bat acceleration in a random/unknown fashion, etc … your timing will be off. You have to learn to bring your ‘A’ swing every time – it’s the only way you are going to develop the connection between what your eyes are telling your body it needs to do, and what it actually does. Hitting off tees and with soft toss etc. are useful exercises in terms of learning, and developing that consistent swing so that when the player gets up to bat against a real good pitcher, they have the ability and confidence to take control of the situation and dictate how the at bat will be played. They will make the pitcher have to pitch around their strength rather than having to react to what is happening. They will already know what will happen, because they know themselves – inside and out – and there will be no guessing.

    • Joey Myers
      Joey Myers says:

      I totally agree with you Bob. And I’ll piggy back on that…a younger hitter NEEDS to have more physical swings because they’re knew to movement. The older the hitter gets, say a Big Leaguer at age 30, it’s more important to replace (not completely) physical swings with mental ones. A 162-game season is brutal on the body. Studies show that whether a person takes a mental or physical swing, the brain doesn’t know the difference.

  4. Paul
    Paul says:

    Joey
    i’m finishing your book now. i believe my son is hitting the ball on the ground too much due to a straightening back leg. is this a thought/drill for him to work on to help with that?
